MECHETEC PPO
MECHETEC® PPO (blend of polyphenylene oxide and styrene) is an amorphous thermoplastic that offers a superior blend of physical strength, flame resistance, and outstanding electrical properties. Unlike many amorphous materials that tend to steadily lose strength as temperatures increase, MECHETEC® PPO maintains its high stiffness to temperatures in excess of 200°F.
In addition, it’s low moisture absorption and low coefficient of thermal expansion contribute to it being one of the most dimensionally stable materials available. MECHETEC® PPO has an excellent V-0 UL-94 flame rating at thicknesses of 0.24″ and over. For applications that require improved strength and stiffness, 30% glass fiber filled is available.
Formally known as Uninor PPO. For more Info :
Have questions or need samples?
Features
- 230 ° F Continuous Use Temperature
- Excellent Dimensional Stability
- Low Moisture Absorption
- High Dielectric Strength
- Flame Resistant
Colors
Black
Glass - Filled
Applications
- Manifolds
- Electrical Insulators
- Electrical Connectors
- Aircraft Instrumentation
- Business Equipment Housings
Formulations
- 30% Glass-Filled
Sizes
Unfilled
Extruded Sheet
Thickness
0.25 – 4.00 inch / 6 – 102 mm
Sheet Size
24 x 48 inch / 610 x 1220 mm
Extruded Rod
Diameter
0.375 – 8.00 inch / 10 – 203 mm
Length
96 inch / 2438 mm
Glass-Filled
Extruded Sheet
Thickness
0.25 – 4.00 inch / 6 – 102 mm
Sheet Size
24 x 48 inch / 610 x 1220 mm
Extruded Rod
Diameter
0.375 – 8.00 inch / 10 – 203 mm
Length
96 inch / 2438 mm
Resources
Brochure
Typical Properties
Safety Data Sheet
